Double Sides Labeling Machine

Application:

Automatic Double Sides Labeling Machine is mainly used in chemical, food and pharmaceutical industry. It is also suitable for flat, square and irregular containers.




Details:

Tel/Whtasapp: 18664230858
Feature:
Application:
Samples:
Specification:
Combined Parts:
Inquiry
Feature:

1.Applicable to the pharmaceutical, food, cosmetic and other light industrial products such as oval, square, flat bottles on the single and double sides labeling.

2.The man-machine interface system is advanced and compatible, easy operation, complete functions, has a wealth of online help function.

3.The bottle dividing device shaped general, any diameter of the bottle without replacement parts, rapid positioning adjustment; Bilateral chain correction device ensure the material on the neutral;

4.Special elastic pressing equipment ensure seeding materials stability;

5.Automatic optical inspection, have nothing items come without labeling, and without label automatic correction or alarm and automatic detection function, to prevent leakage and waste;

6.Labeling speed, conveyor speed, sub-bottle speed stepless speed, adjust as needed;


Application:

Automatic Double Sides Labeling Machine is mainly used in chemical, food and pharmaceutical industry. It is also suitable for flat, square and irregular containers.


Samples:

Samples-Bottle labeling machine.jpg


Specification:

Model

BE-300D Double side labeling machine

Labeling capacity(pcs/min)

40-100pcs/min (Related to the material and label size)

Labeling accuracy(mm)

±1.0mm

Label size

Double side width 180mm,Label length not more than 280mm

Bottle size:

Bottle not bigger than 120mm width,Height ≤330mm

Roll inside(mm):

Φ76mm

Roll outside diameter(mm):

MAX Φ350mm

Machine size (mm):

(L)2400*(W)1000*(H)1700(mm)

Power supply:

AC220V 50Hz/60Hz 2000W


Combined Parts:
